Air Operated Double Diaphragm Pump (AODD)
Grosvenor AODD Pumps are air operated double diaphragm pumps — an affiliate product developed in
technical collaboration with Pumpefrima Mapex, Norway. These pumps are ideal for
handling corrosive, viscous, shear-sensitive, and abrasive fluids across a wide range of industries.
Available in multiple sizes and materials of construction to suit every application
requirement.
MOCs Available : PPH, PVDF, SS-316, AL
AODD 150 / ½" BSP (15 MM)
Technical Specifications
| Max Flow Rate | 35 Lpm |
| Inlet Port Size | 12.70 mm (½" BSP) |
| Discharge Port Size | 12.70 mm (½" BSP) |
| Air Inlet | ¼" BSP |
| Air Exhaust | 12.70 mm (½" BSP) |
| Suction Lift (Dry) | 1.45 m (4.75') |
| Suction Lift (Wet) | 2.83 m (9.28') |
| Teflon (Dry) | 0.50 m (1.64') |
| Teflon (Wet) | 0.90 m (2.95') |
| Max Particle Size (Dia) | 2 mm (0.078") |
AODD 300 / 1" BSP (25 MM)
Technical Specifications
| Max Flow Rate | 135 Lpm |
| Inlet Port Size | 25.40 mm (1" BSP) |
| Discharge Port Size | 25.40 mm (1" BSP) |
| Air Inlet | 1/4" BSP |
| Air Exhaust | 12.70 mm (½" BSP) |
| Suction Lift (Dry) | 3.05 m (10') |
| Suction Lift (Wet) | 4.89 m (16') |
| Teflon (Dry) | 2.14 m (7') |
| Teflon (Wet) | 3.98 m (13') |
| Max Particle Size (Dia) | 3.17 mm (0.125") |
AODD 400 / 1½" BSP (40 MM)
Technical Specifications
| Max Flow Rate | 270 Lpm |
| Inlet Port Size | 38.10 mm (1½" BSP) |
| Discharge Port Size | 38.10 mm (1½" BSP) |
| Air Inlet | ½" BSP |
| Air Exhaust | 12.70 mm (½" BSP) |
| Suction Lift (Dry) | 4.57 m (15') |
| Suction Lift (Wet) | 7.62 m (25') |
| Teflon (Dry) | 3.05 m (10') |
| Teflon (Wet) | 6.09 m (20') |
| Max Particle Size (Dia) | 4.76 mm (0.188") |
AODD 500 / 2" BSP (50 MM)
Technical Specifications
| Max Flow Rate | 586 Lpm |
| Inlet Port Size | 50.80 mm (2" BSP) |
| Discharge Port Size | 50.80 mm (2" BSP) |
| Air Inlet | ½" BSP |
| Air Exhaust | 19.05 mm (¾" BSP) |
| Suction Lift (Dry) | 4.57 m (15') |
| Suction Lift (Wet) | 7.62 m (25') |
| Teflon (Dry) | 3.05 m (10') |
| Teflon (Wet) | 6.09 m (20') |
| Max Particle Size (Dia) | 6.35 mm (0.250") |
Features
- ✔ Self-priming pump
- ✔ Can run dry without damage
- ✔ No electricity required — air operated
- ✔ Handles corrosive & abrasive liquids
- ✔ Handles shear-sensitive fluids
- ✔ Can handle solids in suspension
Features
- ✔ Robust & compact construction
- ✔ Easy to maintain
- ✔ Variable flow rate control
- ✔ TEFLON diaphragm option available
- ✔ ISO 9001-2015 certified company
- ✔ Available in PPH, PVDF, SS-316, AL
Material of Construction (MOC)
PPH, PVDF, SS-316, Aluminium (AL)
* For TEFLON diaphragms, reduce water discharge figures by 20%.
*** Our policy is to continually develop and improve our products and we therefore reserve the right to modify products without any notice.***
